Medium Temperature Sintered Tunnel Kiln For Clay Brick

Large Image : Medium Temperature Sintered Tunnel Kiln For Clay Brick

Product Details:

Place of Origin:	Jiangsu,China
Brand Name:	Yan Yang Tian
Model Number:	Non-standard customized equipment

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Export package or according the customer's requirement
Delivery Time:	Negotiable
Payment Terms:	T/T, L/C
Supply Ability:	5 Set/Sets per Month

Contact Now

Medium Temperature Sintered Tunnel Kiln For Clay Brick

Description

Kiln Length:	52-150m	Section Size Of Furnace Mouth:	2. 1.5-4.5m Wide; 1.5-2m High (can Be Customized According To Requirements)
Designed Maximum Operating Temperature:	1300℃	Common Temperature:	1000-1250℃
Designed Daily Output (24h):	15000-80000 Standard Bricks	Combustion Power:	1.5-10 Million Kcal
Supporting Electric Power:	30-60Kw/380V	Kiln Structure:	Modular Assembly, 2-3 Meters / Section
High Light:	Sintered Tunnel Kiln , Tunnel Kiln For Clay Brick

Kiln Brick Gas ( Oil ) Clay Building Materials Medium Temperature Sintered Tunnel Kiln

1 , Product Overview

Kilns for construction, refractory and abrasive industries
Medium temperature sintering tunnel kiln for 1300 ℃ gas (oil) clay building materials

Temperature control method:PID automatic temperature control system, touch screen control interface 485 communication, automatic constant temperature,
Temperature adjustable, over temperature alarm and other superior performance.

2 , Parameter attribute table

The main technical parameters
Kiln length	52-150m
Section size of Kiln mouth	1.5-4.5m wide; 1.5-2m high (can be customized according to requirements)
Designed maximum operating temperature	1300℃
Common temperature	1000-1250℃
Designed daily output (24h)	15000-80000 standard bricks
Use fuel	Natural gas, LPG, light oil, heavy oil
Combustion power	1.5-10 million kcal
Supporting electric power	30-60Kw/380V
Temperature zone quantity	Five (preheating zone, constant temperature, slow cooling, rapid cooling, preheating utilization)
Transmission method	Orbital kiln car, internal and external circulation closed operation
Products into the kiln mode	Fully automatic hydraulic propulsion
Exhaust way	The Kiln head power exhaust, design the circulating waste heat utilization mechanism as required
kiln structure	Modular assembly, 2-3 meters / section

3 , Product Usage

Mainly used for construction materials such as clay sintered bricks, clean water bricks, road sintered bricks, split bricks, etc.
High temperature sintering.
Can also be used for: Medium temperature sintering of clay insulation bricks and ceramic products.

Medium Temperature Sintered Tunnel Kiln For Clay Brick 0

4. FAQ

1. Are you a trader or a manufacturer?
We are a company, we have our own factory

2. How long is your delivery time?
Negotiable

3. Can the product be customized?
Can be customized

4. What does the product packaging look like?
Export packaging or according to customer requirements

Please contact us for specific details, we will tailor-made for you!
