Calendered Glass Annealing Industrial Glass Furnace

Calendered Glass Annealing Industrial Glass Furnace
Calendered Glass Annealing Industrial Glass Furnace Calendered Glass Annealing Industrial Glass Furnace Calendered Glass Annealing Industrial Glass Furnace

Large Image :  Calendered Glass Annealing Industrial Glass Furnace

Product Details:
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 5 Set/Sets per Month
Contact Now

Calendered Glass Annealing Industrial Glass Furnace

Description
Temperature Control Precision: ±1℃ Furnace Length: 26-60m
Chamber Width: 800-2500mm Roller Diameter: Ø60-120mm
High Light:

Annealing Industrial Glass Furnace

,

Calendered Glass Industrial Glass Furnace



Glass Furnace Furnace Roller Type Electric Heating Calendered Glass Annealing Furnace



1 , Product Overview



Roller-type electric heating rolled glass continuous annealing furnace,Non-standard customized equipment.

Roller material: according to the needs, cast heat-resistant steel, quartz ceramics, ceramics are used in different parts of the furnace
Tube and other materials

Control mode: PID intelligent control system, multi-point control



2 , Parameter attribute table



The main technical parameters
Furnace length

26-60m
Chamber width

800-2500mm
Roller diameter

Ø60-120mm
Temperature control precision

±1℃
Maximum use temperature

850℃
Transfer method

Helical gear + roller rod transmission

Common temperature

≤800℃
Starting power

120-350Kw/380V
Roller speed Frequency control
Furnace structure Modular; on-site assembly



3 , Product Usage
  1. Non-standard customized equipment, mainly used for thermal annealing of colored glazed glass, embossed glass, microcrystalline glass, jade glass.
  2. It can also be used for the hot bending and hot-melting functions of instrument glass, lighting glass and functional glass.

Calendered Glass Annealing Industrial Glass Furnace 0

Please contact us for details, we will tailor-made for you!
