Lifting Type Optical Glass Precision Annealing Furnace

1 Set
MOQ
Negotiable
Price
Lifting Type Optical Glass Precision Annealing Furnace
Features Gallery Product Description Request A Quote
Features
Specifications
Furnace Effective Volume: 0.5-3.5m³
Power: 40-240KW/380V
Maximum Use Temperature: 1000℃
Temperature Uniformity: ± 3 ℃ (9-point Test)
Heating Method: Heating Around
Chamber Atmosphere: Hot Air Circulation + Uniform Heat Hood + Wind Guide Mechanism
Highlight:

Glass Precision Annealing Furnace

,

Optical Glass Annealing Furnace

,

Lifting Glass Annealing Furnace

Basic Infomation
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5 Set/Sets per Month
Product Description



Glass Furnace Lifting Type Optical Glass Precision Annealing Furnace



1, Product Overview



Lifting type optical glass precision annealing furnace



2, Parameter attribute table



The main technical parameters
Chamber effective volume

0.5-3.5m³(Diameter Ø0.5-1.8m; Height 0.6-2.0m)

Power

40-240Kw/380V

Temperature uniformity ± 3 ℃ (9 point test)
Maximum use temperature 1000℃
Heating method Heating around
Electric heating element Electric heating alloy wire
Chamber atmosphere Hot air circulation + uniform heat hood + wind guide mechanism
Control method PID intelligent program temperature control, touch screen section, 485 communication and other superior performance
Electric or hydraulic lifting mechanism, fall protection secondary protection system
Rail-type electric drive mobile chassis



3, Product application



Non-standard customized equipment, mainly used for precision annealing heat treatment of special optical glass products



Lifting Type Optical Glass Precision Annealing Furnace 0



4. FAQ



1. Are you a trader or a manufacturer?
We are a company, we have our own factory

2. How long is your delivery time?
Negotiable

3. Can the product be customized?
 Yes, it can be customized

4. What does the product packaging look like?
Export packaging or according to customer requirements

Please contact us for details, we will tailor-made for you!
