Product Details:
|
| Furnace Effective Volume: | 0.5-3.5m³ | Power: | 40-240Kw/380V |
|---|---|---|---|
| Maximum Use Temperature: | 1000℃ | Temperature Uniformity: | ± 3 ℃ (9-point Test) |
| Heating Method: | Heating Around | Chamber Atmosphere: | Hot Air Circulation + Uniform Heat Hood + Wind Guide Mechanism |
| High Light: | Glass Precision Annealing Furnace,Optical Glass Annealing Furnace,Lifting Glass Annealing Furnace |
||
Glass Furnace Lifting Type Optical Glass Precision Annealing Furnace
Lifting type optical glass precision annealing furnace
| The main technical parameters | |
| Chamber effective volume |
0.5-3.5m³(Diameter Ø0.5-1.8m; Height 0.6-2.0m) |
| Power |
40-240Kw/380V |
| Temperature uniformity | ± 3 ℃ (9 point test) |
| Maximum use temperature | 1000℃ |
| Heating method | Heating around |
| Electric heating element | Electric heating alloy wire |
| Chamber atmosphere | Hot air circulation + uniform heat hood + wind guide mechanism |
| Control method | PID intelligent program temperature control, touch screen section, 485 communication and other superior performance |
| Electric or hydraulic lifting mechanism, fall protection secondary protection system | |
| Rail-type electric drive mobile chassis | |
Non-standard customized equipment, mainly used for precision annealing heat treatment of special optical glass products
1. Are you a trader or a manufacturer?
We are a company, we have our own factory
2. How long is your delivery time?
Negotiable
3. Can the product be customized?
Can be customized
4. What does the product packaging look like?
Export packaging or according to customer requirements
Please contact us for details, we will tailor-made for you!
