Electric Heating Glass Baking Annealing Furnace Mesh Belt Type

1 Set
MOQ
Negotiable
Price
Electric Heating Glass Baking Annealing Furnace Mesh Belt Type
Features Gallery Product Description Request A Quote
Features
Specifications
Starting Power: 45-270Kw/380V
Maximum Use Temperature: 750℃
Temperature Control Precision: ±1℃
Furnace Length: 10-32m
Mesh Belt Width: 300-4000mm
Transfer Method: 304 / 321 Stainless Steel Mesh Belt, Frequency Conversion Speed Regulation
Highlight:

Glass Baking Annealing Furnace

,

380V Electric Heating Annealing Furnace

Basic Infomation
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 5 Set/Sets per Month
Product Description

Mesh Belt Type Electric Heating Glass Baking (Annealing) Furnace

Equipment purpose

For glass bottles, glass and other utensils and glass cosmetic bottles, etc.

For lighting glass, daily glass, pressing glass (cold) annealing

Maximum temperature 750 ° C
Usual temperature 500-600 ° C
Furnace length 18M-36M
Furnace size Width 300mm-2500mm, height 120mm-350mm (It can be customized according to customer requirements)
Running speed 0 ~ 500mm / min (continuously adjustable)
Mesh belt width 300mm-2500mm
Mesh belt material SUS304, SUS321 stainless steel
Temperature control point 5 ~ 20 points
Temperature control mode Subregional independent control
Instrument control temperature accuracy ± 1 ° C
Uniform temperature in the furnace ≤ ± 5 ° C
heater Quartz tube or electric furnace
Temperature control system PID intelligent temperature control system, touch screen control interface
Features

1. The temperature precision in the furnace is accurate, the homogeneity of the furnace temperature is high, and the product consistency is good.

2, the pneumatic network belt tensioning device equipment operation is stable.

3, all ceramic fiber warming cotton plate structure, rapid temperature rise, energy saving is efficient.

Remarks The above parameters are for reference only, this equipment is non-standard equipment, which is customized according to the actual process requirements of the product.

Mesh Belt Type Glass Fuel Decorating Lehr For Glassware



1, Product Overview



This lehr is mainly used for glass wine bottles, glassware, daily glass and process glass, high-temperature (stained paper) trademark decoration and gold decoration; the total length of the furnace is 28 to 40 meter; the maximal use temperature is 650℃; and it is suitable for large-batch continuous production.



2, Parameter attribute table



1. Lehr length:10-32m

2. Starting power:30-270Kw/380V

3. Transfer method:304 / 321 stainless steel mesh belts, frequency conversion speed regulation.

4. Mesh belt width:300-4000mm

5. Maximum use temperature:750℃

6. Temperature control precision:±1℃

7. Control mode:PID intelligent control system, multipoint control.

8. Hot air circulation :Mesh belt width ≥1.2m can consider by hot air circulation

9. Lehr structure: Modular; on-site assembly



3, Product Usage
  1.  Non-standard custom equipment, mainly used for daily use glassware such as glass bottles, glass cups and other glass products high and low temperature decorating (high temperature glass ink, drawing paper)
  2. Can also be used for: daily use glass, pressed glass, lighting glass and other cold and hot annealing heat treatment.



Electric Heating Glass Baking Annealing Furnace Mesh Belt Type 0

Electric Heating Glass Baking Annealing Furnace Mesh Belt Type 1



4, Overview features


The production process is that the product is placed on the mesh belt, driven by the mesh belt, and heated from the feed end into the furnace through the furnace opening to form, then gradually cooled by the cooling chamber, and then collected by the discharge end to complete the entire heat treatment process.

Please contact us for details, we will tailor-made for you!
