1700 ℃ Electric Rare Earth Continuous Mesh Belt Furnace

1 Set
MOQ
Negotiable
Price
1700 ℃ Electric Rare Earth Continuous Mesh Belt Furnace
Features Gallery Product Description Request A Quote
Features
Specifications
Chamber Size: 10000mm × 280mm × 220mm
Common Temperature: 1600-1680 ℃
Supporting Push Plate Size: 250mm × 250mm × 30mm
Electric Heating Element: Molybdenum Wire
Maximum Use Temperature: 1700℃
Way Forward: Hydraulic Propulsion Full Automatic Slewing Mechanism
Highlight:

Rare Earth Mesh Belt Furnace

,

1700 ℃ Continuous Mesh Belt Furnace

Basic Infomation
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Model Number: Non-standard customized equipment
Payment & Shipping Terms
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5 Set/Sets per Month
Product Description



1700 ℃ Atmosphere Protection Rare Earth High Temperature Calcination Electric Heating Push Furnace



1, Product Overview

Catalyst furnace for rare earth industry :1700 ℃ Atmosphere Protection Rare Earth High Temperature Calcination Electric Heating Push furnace

1700 ℃ Electric Rare Earth Continuous Mesh Belt Furnace 0

2, Parameter attribute table

The main technical parameters
Chamber size 10000mm × 280mm × 220mm
Supporting push plate size 250mm × 250mm × 30mm
Chamber protective atmosphere Hydrogen + nitrogen, adjustable flow and controllable
Maximum use temperature

1700℃

Common temperature 1600-1680 ℃
Electric heating element Molybdenum wire
Temperature control method PID intelligent program temperature control system, with automatic constant temperature, adjustable temperature, over-temperature report
Police and other superior performance
Chamber material Alumina hollow sphere + corundum mullite
Way forward Hydraulic propulsion full automatic slewing mechanism

Please contact us for more details, we will tailor-made for you!
