PID Control 26-60m Crystal Glass Mosaic Production Line

1 Set
MOQ
Negotiable
Price
PID Control 26-60m Crystal Glass Mosaic Production Line
Features Gallery Product Description Request A Quote
Features
Specifications
Roller Diameter: Ø40-60mm
Maximum Use Temperature: 1000℃
Temperature Control Precision: ±1℃
Furnace Length: 26-60m
Common Temperature: ≤900℃
Furnace Structure: Modular; On-site Assembly
Transfer Method: Helical Gear Transmission
Chamber Width: 800-2500mm
Highlight:

Crystal Glass Mosaic Production Line

,

PID Control glass mosaic production line

,

60m Crystal Glass Mosaic Production Line
Basic Infomation
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 5 Set/Sets per Month
Product Description



Crystal glass mosaic production line with glass furnace length of 26-60m



1, Product Overview



The company provides crystal glass mosaic production line



2, Parameter attribute table



The main technical parameters
Furnace length

26-60m
Roller diameter

Ø40-60mm
Chamber width

800-2500mm
Temperature control precision

±1℃
Maximum use temperature

1000℃
Transfer method

Helical gear transmission
Heating mode Electricity, natural gas, liquefied petroleum gas
Control mode PID intelligent control system, multipoint control

Common temperature

≤900℃
Daily output (24h) 100-1500 square meters / day
Roller speed Frequency control
Roller material Use stainless steel rollers and high temperature ceramic rollers in different parts of the Furnace as required
Furnace structure Modular; on-site assembly



3, Product Usage



Uses: Non-standard customized equipment, mainly used for the continuous production of crystal glass mosaics
Production line equipment composition: glass cutting machine, printing and drying line, breaking and typesetting machine, edge melting furnace, back film drying line and other equipment.

Our company provides a full set of technology and equipment for crystal mosaic production, please contact us for details, we will tailor it for you!
