Temperature Control Glass Annealing Electric Industrial Furnace

Temperature Control Glass Annealing Electric Industrial Furnace
Temperature Control Glass Annealing Electric Industrial Furnace Temperature Control Glass Annealing Electric Industrial Furnace

Large Image :  Temperature Control Glass Annealing Electric Industrial Furnace

Product Details:
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 5 Set/Sets per Month

Temperature Control Glass Annealing Electric Industrial Furnace

Description
Common Temperature: ≤800℃ Furnace Length: 26-60m
Chamber Width: 800-2500mm Roller Diameter: Ø60-120mm
Brand: Yan Yang Tian Certificate: CE
Temperature Control Precision: ±1℃ Transfer Method: Bevel Gear + Roller Transmission
High Light:

Glass Annealing Electric Industrial Furnace

,

Temperature Control Glass Annealing Furnace

,

Bevel Gear Continuous Annealing Furnace



Glass Furnace Temperature Control Accuracy Of Glass Annealing Furnace ± 1 ℃



1 , Product Overview



Roller-type electric heating rolled glass continuous annealing furnace,Non-standard customized equipment.

Roller material: according to the needs, cast heat-resistant steel, quartz ceramics, ceramics are used in different parts of the kiln
Tube and other materials



2 , Parameter attribute table



The main technical parameters
Furnace length

26-60m

Chamber width

800-2500mm

Roller diameter

Ø60-120mm

Temperature control precision

±1℃

Maximum use temperature

850℃

Transfer method

Bevel gear + roller  transmission

Control mode PID intelligent control system, multi-point control

Common temperature

≤800℃

Starting power

120-350Kw/380V

Roller speed Frequency control
Furnace structure Modular; on-site assembly



3 , Product Usage
  1. Non-standard customized equipment, mainly used for thermal annealing of colored glazed glass, embossed glass, microcrystalline glass, jade glass.
  2. It can also be used for the hot bending and hot-melting functions of instrument glass, lighting glass and functional glass.

Temperature Control Glass Annealing Electric Industrial Furnace 0

Temperature Control Glass Annealing Electric Industrial Furnace 1



4. FAQ



1. What does the product packaging look like?
Export packaging or according to customer requirements

2. Are you a trader or a manufacturer?
We are a company, we have our own factory

3. How long is your delivery time?
Negotiable

4. Can the product be customized?
Can be customized

Please contact us for details, we will tailor-made for you!
