Mesh Belt High Temperature Glass Decorating Furnace PID Control

1 Set
MOQ
Negotiable
Price
Mesh Belt High Temperature Glass Decorating Furnace PID Control
Features Gallery Product Description Request A Quote
Features
Specifications
Starting Power: 45-270Kw/380V
Temperature Control Precision: ±1℃
Furnace Length: 10-32m
Transfer Method: 304 / 321 Stainless Steel Mesh Belt, Frequency Conversion Speed Regulation
Furnace Structure: Modular; On-site Assembly
Maximum Operating Temperature: 750℃
Hot Air Circulation: Mesh Belt Width ≥1.2m Can Consider Hot Air Circulation
Control Mode: PID Intelligent Control System, Multi-point Control
Application: Industrial Heating
Control System: PID Control System
Fuel: Electricity
Heating Element: Electric Heating Element
Material: Stainless Steel
Name: Electric Industrial Furnace
Power: High
Safety System: High Temperature Alarm System
Size: Customizable
Temperature: High
Temperature Range: 50-1200℃
Type: Industrial Furnace
Voltage: 220V-440V
Warranty: 1 Year
Highlight:

PID Control System Glass Furnace

,

High Temp Glass Decorating Furnace

,

Mesh Belt Type Glass Furnace

Basic Infomation
Place of Origin: Jiangsu,China
Brand Name: Yan Yang Tian
Certification: CE
Model Number: Non-standard customized equipment
Payment & Shipping Terms
Packaging Details: Export package or according the customer's requirement
Delivery Time: Negotiable
Payment Terms: T/T, L/C
Supply Ability: 5 Set/Sets per Month
Product Description

Electric Mesh Belt High Temperature Glass Decorating Furnace Mesh Belt Furnace



1, Product Overview



Mesh Belt Type Electric Glass Decorating (Annealing) Furnace, Suitable for mass production



2, Parameter attribute table



The main technical parameters
Furnace length

10-32m

Starting power

45-270Kw/380V

Temperature control precision

±1℃

Maximum use temperature

750℃

Mesh belt width

300-4000mm

Hot air circulation Mesh belt width ≥1.2m can consider hot air circulation
Control mode PID intelligent control system, multipoint control

Furnace structure

Modular; on-site assembly
Transfer method 304 / 321 stainless steel mesh belts, frequency conversion speed regulation



3, Product Usage
  1.  Non-standard custom equipment, mainly used for daily use glassware such as glass bottles, glass cups and other glass products high and low temperature Decorating (high temperature glass ink, drawing paper)
  2. It also can be used for: daily use glass, pressed glass, lighting glass and other cold and hot annealing heat treatment.
  3. This series of mesh belt furnace unit is mainly used for hot bending treatment of glass products and handicrafts, and can also be used for annealing and baking treatment of glass products, with a wide range of uses.

Mesh Belt High Temperature Glass Decorating Furnace PID Control 0



4, Overview features


The production process is that the product is placed on the mesh belt, driven by the mesh belt, and heated from the feed end into the furnace, through the furnace opening to form, then gradually cooled in the cooling chamber, and then collected in the discharge end to complete the entire heat treatment process.



5, Package

Delivery period:
Shipped within 45 days from the date of payment by the buyer
Packing: Export package or according to the customer's requirement

Please contact us for details, we will tailor-made for you!
