Product Details:
|
| Temperature Uniformity: | ± 5 ℃ (constant Temperature Area) | Design Maximum Operating Temperature: | 1700℃ |
|---|---|---|---|
| Way Of Entering Plate: | Single Push Plate, Double Push Plate | Supporting Push Plate Conventional Size: | 250mm×250mm；320mm×320mm, Etc. |
| Common Temperature: | 1400-1600℃ | Certificate: | CE |
| High Light: | Electronic Ceramic Sintering Furnace,Gas Push Ceramic Sintering Furnace |
||
Ceramic Furnace Furniture Electronic Ceramic High Temperature Gas Push Plate Furnace
Electronic ceramic firing high-temperature gas push plate furnace
| The main technical parameters | |
| Chamber length |
9-15m |
| Common temperature |
1400-1600℃ |
| Temperature uniformity | ± 5 ℃ (constant temperature area) |
| Design maximum operating temperature |
1700℃ |
| Production into the furnace mode | Single push plate, double push plate |
| Supporting push plate conventional size | 250mm × 250mm; 320mm × 320mm, etc. |
| Heating temperature zone | Zone 5-8, 10-16 temperature control points, push the upper and lower temperature control |
| Control mode | SCR control, intelligent instrument PID continuous adjustment, PLC + touch screen automatic monitoring |
| Furnace structure | Modular assembly |
| Propulsion mode | Fully automatic hydraulic propulsion external circulation system |
| Electric heating element | Silicon molybdenum rod |
1. Are you a trader or a manufacturer?
We are a company, we have our own factory
2. How long is your delivery time?
Negotiable
3. Can the product be customized?
It can be customized.
4. What does the product packaging look like?
Export packaging or according to customer requirements
Please contact us for specific details, we will tailor-made for you!
