Daily Ceramic Firing Gas Tunnel Kiln Industrial Ceramic Furnace
It is mainly used for high-temperature firing of daily ceramic tableware, suitable for large-scale continuous production.
Tunnel furnace is a kind of light energy-saving continuous production furnace. The kiln is an assembled metal frame structure, and the masonry is made of high-grade light-weight refractory and thermal insulation materials.
| The main technical parameters | |
| Furnace length |
36-60m |
|
Chamber section size |
800-1500mm wide |
| Electric power |
≯60Kw/380V |
| Heating mode | Natural gas special burner furnace body heating on both sides |
| Maximum operating temperature |
1350℃ |
| Common temperature |
1000-1300℃ |
| Control mode | PID intelligent temperature control system partition multipoint control, touch screen control section, with automatic constant temperature, temperature Adjustable over temperature alarm and other superior performance. |
|
Furnace car surface mounted product height |
1-1.5m |
| Fuel | Natural gas, liquefied petroleum gas, cold gas |
| Transmission mode | Furnace car type, external circulation mechanism |
| Smoke exhaust mode | Utilization of waste heat, smoke exhaust from furnace body |
| Grouped equipment | Full-automatic outer circulation rotary line |
| Furnace structure | Modular assembly |
| Propulsion mode | Furnace head hydraulic propulsion, speed adjustable |
Please contact us for specific details, we will tailor-made for you!
1. Are you a trader or a manufacturer?
We are a company, we have our own factory.
2. How long is your delivery time?
Negotiable
3. Can the product be customized?
Yes, it can be customized.
4. What does the product packaging look like?
Export packaging or according to customer requirements.
