1300 ℃ Gas - Fired Insulation Bricks, Permeable Bricks, Sintered Push - Plate Kiln
| The main technical parameters | ||
| Serial number | name | Description |
| 1 | Product Size |
Water brick: 215x67x100 2.9kg, 230x76x70 1.8kg |
| 2 | Design capacity | 10,000–13,000 pieces / 24h |
| 3 | Kiln type |
Double-hole four-plate fuel tunnel kiln |
| 4 | Design maximum operating temperature |
1200℃ |
| 5 | Sintering temperature |
1150℃ |
| 6 |
Sintering process |
The preheating zone is heated at 100-700 ℃ for about 6 hours; the firing zone is at 1130 ℃ for about 5 hours and the slow cooling zone is about 4 hours. The outlet temperature is 80 ℃ |
| 7 | Production mode | 24 hours continuous production |
| 8 | Push plate size |
460mm×320mm×55mm |
| 9 | Load quantity of each board | 15 pieces (5 pieces per layer, 3 layers superimposed) |
| 10 | Number of boards | 4 push plates at a time |
| 11 | Boarding time | About 7–8 minutes / time |
| 12 | Push mode | Four sets of hydraulic cylinders advance at the same time or in sequence; the advancement speed is adjustable |
| 13 | Unloading method | External circulation line operation or furnace mouth manual operation |
| 14 | Fuel | Natural gas, liquefied petroleum gas, light oil |
| 15 | Temperature zone arrangement | Preheating zone, heating zone, sintering zone, slow cooling zone, air cooling / quenching zone |
| 16 | Kiln area | Length about 45m. Width about 3.5m. Height about 2.5m (width does not include external circulation) |
| 17 | weight | About 240 tons |
Please contact us for specific details, we will tailor-made for you!
